Description
Introduction
YG vertical explosion-proof pipeline oil pump is an extension of the ISG series single-stage single-suction pipeline centrifugal pump. It is designed for the transportation of petroleum products such as gasoline, kerosene, and diesel. It adopts the performance parameters of the IS type centrifugal pump and is ingeniously combined and designed based on the general vertical pumps. At the same time, according to different usage temperatures and media, products suitable for transporting oil-based media are derived from the ISG type centrifugal pump. This series of products has the advantages of high efficiency, low noise, and reliable performance. It complies with the new national mechanical department JB/T5305 8-93 standards. The product is designed and manufactured in accordance with the international IS02858 standard. This series of products all use national standard explosion-proof motors, with explosion-proof grades of DIIBT4 and protection grades of IP54. The impellers are made of high-quality brass.
Performance
Flow 1-500m³ / h;
Head 10-125m;
Speed:2950rpm,1450rpm
Temperature -20 ° C; - 120 ° C';
Installation : Vertical , Horizontal ;
Material: HT200; ZG230-450; 1Cr18Ni9Ti,OCr18Ni12-Mo2Ti
Feature
1.·The pump is of a vertical structure. The inlet and outlet diameters are the same and are located on the same central line. It can be installed in the pipeline just like a valve.
2. The impeller is directly installed on the extended shaft of the motor. It has a short axial dimension, a compact and aesthetically pleasing structure, occupies a small area, requires low construction costs, and can be used outdoors with the addition of a protective cover.
3. The pump and motor bearings are properly configured, which can effectively balance the radial and axial loads generated during the pump's operation. This ensures the smooth operation of the pump with low vibration and low noise.
4. The shaft seal adopts mechanical seal or a combination of mechanical seals. It uses imported titanium alloy sealing rings, medium-sized high-temperature resistant mechanical seals and hard alloy materials. The wear-resistant seal can effectively extend the service life.
5. Installation and maintenance are convenient. There is no need to disassemble the pipeline system. All the rotor components can be withdrawn simply by removing the pump coupling seat nut.
Application
YG vertical single-stage single-suction explosion-proof oil pump is suitable for use in industries such as metallurgy, chemical engineering, textile, wood processing, papermaking, as well as in boilers for hot water circulation in hotels, bathrooms, guesthouses, etc. It is also used for heating circulation in urban housing. The operating temperature should be below 105℃.
Configuration
Technical Specification
