Description
Introduction
XBC type diesel engine type self-priming sewage pump, self-priming pump set diesel engine self-priming and non-clogged drainage at a suit, can be like general water self-priming pump without the bottom valve, needs no introduction water and suction sewage containing large granular solid block, long fiber, sediment waste ore impurities, sewage waste treatment and all engineering material, reduce the labor intensity of workers, completely And use, move, easy to install, little maintenance, stable performance. The flexibility of the pump is enhanced by the mobility of the diesel engine and the fact that no wires are needed.
Environmental and Working Conditions
Flow : 10-460m³/h
Head : 10-125m
Medium: water,
Diesel engine speed range: 1450-2900r/min
Water pump flowing parts material: cast iron, stainless steel.
Pump seal form: packing seal, mechanical seal.
Product configuration:
1, water pump: ZW series single stage self-priming type.
2, diesel engine: single cylinder, double cylinder, four cylinder, six-cylinder diesel engine, the speed: 1500 r/min1800r/min2400 / min, etc.
3, other accessories: filter system, silencer system, cooling system, fuel tank, public channel steel base, heat sink, battery, charger.
4, control cabinet: single board machine, PLC programmer, sensor, automatic control cabinet.
Standard scope of supply:
- Diesel pump unit: diesel engine, water pump, coupling, cooling fan, cooling water tank, steel structure base (including the bottom tank 80-120L), battery and connecting wire, exhaust muffler, control screen.
- The standard design is a compound type of pump group, oil tank at the bottom of the machine, control panel and battery group.
- According to customer requirements, it can be designed into pump group, oil tank at the bottom of the machine, control screen, battery group, outdoor rain box compound outdoor type.
- According to customer requirements can be designed into trailer (four or two wheels) mobile type.
Technical Specification
